ISO Certified Manufacturer
SS tile corner trim
Stainless steel corner tile trim specification
Stainless steel corner tile trim specification
| SPECIFICATION | DETAILS |
|---|---|
| Material | 304/316 Stainless steel |
| Length | 2440 mm |
| Thickness | 0.6, 0.8, 1.0 mm/customized |
| Height | 8/10/12 mm or customized |
| Surface Treatment | Brushed, BA, mirror |
| Applications | Finishing corners, Protecting tile edges |
Stainless steel corner tile trim
SS tile corner trim
Stainless steel corner trim
SS corner edge trim
Stainless steel outside corner trim
SS corner trim
Stainless steel corner trim application
- Exterior Use
- Kitchen & Bathroom
- Wall and Floor Edges
- Decorative Edges
SS corner edge trim sizes
SS corner edge trim sizes
| Size (mm) | Width | Thickness | Length | Weight (kg/m) |
|---|---|---|---|---|
| 10 x 10 | 10mm | 0.8mm | 2500mm, 3000mm, 4000mm | 0.15 kg |
| 12 x 12 | 12mm | 1.0mm | 2500mm, 3000mm, 4000mm | 0.20 kg |
| 15 x 15 | 15mm | 1.2mm | 2500mm, 3000mm, 4000mm | 0.25 kg |
| 20 x 20 | 20mm | 1.5mm | 2500mm, 3000mm, 4000mm | 0.35 kg |
| 25 x 25 | 25mm | 2.0mm | 2500mm, 3000mm, 4000mm | 0.45 kg |
| 30 x 30 | 30mm | 2.5mm | 2500mm, 3000mm, 4000mm | 0.55 kg |
Color option of stainless steel outside corner trim
- Rose Gold PVD Coating
- Brushed Stainless Steel
- Custom Coatings
- Polished Stainless Steel
- Black PVD Coating
- Gold PVD Coating
- Chrome Plated
SS corner trim chemical composition
SS corner trim chemical composition
| Grade | STS304 | STS 316 | STS430 | STS201 |
|---|---|---|---|---|
| Elong(10%) | Above 40 | 30MIN | Above 22 | 50-60 |
| Hardness | ≤200HV | ≤200HV | Below 200 | HRB100,HV 230 |
| Cr(%) | 18-20 | 16-18 | 16-18 | 16-18 |
| Ni(%) | 8-10 | 10-14 | ≤0.60% | 0.5-1.5 |
| C(%) | ≤0.08 | ≤0.07 | ≤0.12% | ≤0.15 |
Brushed stainless steel corner trim mechanical properties
Brushed stainless steel corner trim mechanical properties
| Property | Value |
|---|---|
| Tensile Strength | 550–700 MPa (depends on grade) |
| Hardness | Rockwell B70–80 |
| Elongation | 40–50% |
| Yield Strength | 240–290 MPa (depends on grade) |
Equivalent grades of stainless steel corner molding
Equivalent grades of stainless steel corner molding
| Material | Equivalent Grades |
|---|---|
| 304 Stainless Steel | AISI 304, EN 1.4301 |
| 316 Stainless Steel | AISI 316, EN 1.4401 |
Brushed steel corner trim characteristic
Brushed steel corner trim characteristic
| Characteristic | Description |
|---|---|
| Material | High-quality stainless steel (304 or 316 grades) |
| Protection | Protects tile edges from cracks, chips, and damage |
| Durability | Resistant to rust, corrosion, and staining |
| Finish Options | Brushed, polished, satin, and matte finishes |
| Customizable | Available in various colors, sizes, and finishes |
| Ease of Installation | Quick and simple installation with minimal tools |
FAQ
What finishes are available for stainless outside corner trim?
- Brushed Finish (Hairline)
- Satin Finish
- Matte Finish
- Polished Finish (Mirror)
- PVD Coated – Gold, Black, Bronze, Rose Gold
- Bead Blasted Finish
- Antique Finish
What is the difference between brushed and polished SS corner tile trim?
What is the difference between brushed and polished SS corner tile trim?
| Finish | Look | Key Difference |
|---|---|---|
| Polished | Glossy and mirror-like | Smooth surface, highly reflective |
| Brushed | Matte with fine lines | Textured surface, less reflective |
Can stainless steel corner tile trim be cut to custom lengths?
- Yes, it can be cut to custom sizes.
- Standard lengths are usually 2.5m, 3m, and 4m.
- Can be cut using a hacksaw or grinder.
- Use fine-tooth blades for clean cuts.
